CBB65 450V 20UF Round Type Capacitor S2 ROHS Air Compressor 3000 Hours C-Class

Brand Name : XWD

Model Number : CBB65 AC Motor Capacitor

Certification : UL / CQC / VDE

Place of Origin : CHINA

MOQ : 10 pieces

Price : To be negotiated

Payment Terms : T/T, L/C, D/P

Supply Ability : 10000 Pieces per Day

Delivery Time : 7-20 workdays

Packaging Details : Carton / 525×275×180mm

Name : AC Motor Capacitor

Product code : XWD-XHNCZKT045

Voltage Rating : 450V.AC

Capacitance : 20UF

Size : 45mm*75mm(1-49/64in*2-61/64in)

Supplier Type : Original Manufacturer / ODM / OEM

Connection Type : Two Quick-connect Terminals

Material : Aluminum

Contact Now

CBB65 450V 20UF Round Type Capacitor S2 ROHS Air Compressor 3000 Hours C-Class

CBB65 Motor Run Capacitors (Round-Shaped, Single Capacitance Value or daul Capacitance Value).CBB65 Motor Run Capacitors feature a low-loss, self-healing Metalized Polypropylene Film dielectric system, which are castor oil-filled.The motor run capacitors with Single capacitance value are offered in voltages ranging from 240 through 660 VAC and with Single capacitance range of 0.5 to 120 microfarads.

Applications

Widely used in the starting and operation of motors (compressors) of air conditioners, washing machines, dishwashers, fans and other electrical equipment.

Basic Info.(Techical Parameters)

Rated frequency	50/60Hz
Rated Voltage	450V.AC
Capacitance Range	20UF
Capacitance tolerance	±5%
Withstand voltage test	2Un 2S
Operating temperature range		-40℃~+85℃(-40/85/21)

Rated Voltage	250V.AC-600V.AC
Capacitance Range	3uF~100uF
Capacitance tolerance	±5% (J),±10%(K)
Tangent of loss angle(20℃)	≤0.0010(at 100Hz)
Dissipation factor	≤0.2%(100Hz)
Climatic cctegory	-40°C~105°C
Operation life time	A Class(30000h)B Class(10000h) C lass (3000h)D lass(1000h)
Withstand voltage	Withstand voltage between terminals	UL:1.5Un/2sOthers:2.0Un/2S
	WVithstand voltage terminals to case	≥2000VAC/2S
Apply certificate	CQC,VDE,UL,CUL,CSA

CBB65 450V 20UF Round Type Capacitor S2 ROHS Air Compressor 3000 Hours C-Class

Operation temperature range	-40℃~+105℃(40170121 40/85121 40/105/21)
Rated Voltage	250V.AC-600V.AC
Capacitance Range	3uF~120uF
Capacitance tolerance	±5% (J),±10%(K)
Tangent of loss angle(20℃)	≤0.0010(at 100Hz)
Insulation resistance	Rc>5000s(100V.DC 60s)
Flammability	UL94V-0
Operation life time	3000H(C Class)at 70℃/10000H(B Class) at 85℃ /30000H(A Class)at 85℃
Withstand voltage	2.0Un (VAC)/60s(CQC, VDE, TUV)
	1.5Un (VAC)/60s (UL)
	2.0Un+1000(VAC)/60s(≥2000VAC)
Class of safety protection	UL VDE CQC(SO) / UL TUV CQC(S3)
